Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	200 W
DMX channels:	5
Control:	Sound to light via microphone
Beam angle (1/2 peak):	20°
Dimensions:	Width: 36 cm Depth: 30 cm Height: 29 cm
Weight:	9.20 kg
Beam angle:	20°
DMX channels:	5
DMX connection:	3-pin XLR
Sound-control:	via built-in microphone
Dimensions (L x W x H):	360 x 300 x 290 mm

Packaging units

PU	EAN	Weight	Dimensions
1	4026397185751	11,00 kg	50cm x 38cm x 33,5cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

DMX protocol

Name	Version	Language
51837558-DMX-6924-de_en_es_fr.xls (32 KB)	0.0000	de_en_es_fr

Support

Name	Version	Language
51837558-Support-14137-de_en_es_fr.dsp (8 KB)	0.0000	de_en_es_fr

Data sheet

Press report

Name	Version	Language

Service document

Name	Version	Language
51837558-Service-6040-1.0000-de.pdf (194 KB)	1.0000	de

Video file

Name	Version	Language
51837558-Video-40122-de_en_es_fr.flv (4 MB)	0.0000	de_en_es_fr

All images

Name	Version	Language
51837558-Images-.zip

Video link

FUTURELIGHT EVO-5 effect-projector

The article is no longer in our assortment.

No. 51837558

Prism effect-projector

DMX-controlled operation or stand-alone operation with Master/Slave function (1 slave)
Multicolor color fan
Gobo-wheel with 5 rotating gobos
Rotating prism
For CDM 150 lamp
DMX control via every standard DMX controller
Can be operated in 5 CH mode
Control via sound to light via microphone
For further information about this product, please refer to the Data Sheet under "Downloads"

Technical specifications

Spare parts

User manual

Downloads

Manufacturer information

Accessories
