Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	460 W
Max. TILT movement:	90° positioning
Max. PAN movement:	180° positioning
Flash rate:	1 - 7 Hz
Equipment:	Gobo wheel with rotating gobos
Gobos:	Gobo wheel with rotating gobos, 8 gobos and open Outside diameter 25mm Image diameter 20mm Gobos changeable
DMX channels:	6
Control:	Sound to light via microphone
Dimensions:	Width: 27 cm Depth: 55.5 cm Height: 28.5 cm
Weight:	8.95 kg
DMX channels:	6
DMX connection:	3-pin XLR
Sound-control:	via built-in microphone
Flash-rate:	1-7 Hz
Color-wheel:	7 dichroic + white
Gobo-wheel:	7 rotating gobos and open
Outside diameter of the gobos:	25 mm
Image diameter of the gobos:	20 mm
PAN-movement:	within 180°
TILT-movement:	within 90°
Dimensions (L x W x H):	555 x 270 x 285 mm

Packaging units

PU	EAN	Weight	Dimensions
1	4026397120875	10,25 kg	58,5cm x 30,5cm x 32,5cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

DMX protocol

Name	Version	Language
51786035-DMX-4319-de_en_es_fr.pdf (63 KB)	0.0000	de_en_es_fr
51786035-DMX-4353-de_en_es_fr.doc (36 KB)	0.0000	de_en_es_fr

Support

Name	Version	Language
51786035-Support-14185-de_en_es_fr.dsp (5 KB)	0.0000	de_en_es_fr
51786035-Support-30567-1.0000-CP-1024-file-de.fx4 (2 KB)	1.0000	de
51786035-Support-57779-Geraetefile-fuer-Eurolite-PC-Software-de.lpp (8 KB)	0.0000	de
